TOP PRO Avolites Tiger Touch II Lighting Console

TOP PRO Tiger Touch II Lighting Console – Seamless Control for Professional Lighting

The Tiger Touch II is the most in-demand Titan console, now upgraded with a screen that’s 100% brighter, enhanced processing power, and a faster graphics engine for seamless performance.

Engineered for professionals, this third-generation lighting console strikes the perfect balance between power and portability. Whether you’re running a large-scale production or touring internationally, the Tiger Touch II compact design makes it easy to transport—even in standard airline luggage.

With advanced features like SMPTE timecode support and a refined button layout aligned with the full Titan range, the Tiger Touch II delivers precision, flexibility, and unmatched control—making it the go-to choice for lighting designers worldwide.

Main features

• 10 main playback faders, with 60 pages
• 10 further preset faders
• 3 optical attribute encoders
• 15.6″ main touch screen with brightness control
• Fully integrated UPS with on-screen warning and countdown
• Triggering via MIDI messages and Time Code
• 4 physical DMX outputs, up to 16 over ArtNet or sACN – 8192 channels
• Supports Titan Network Processors for DMX expansion up to 64 universes

Hardware features

• 20 playback faders – 10 Macro / Executor buttons
• 15.6″ high-brightness touchscreen
• Expand control surface with optional Tiger Touch Fader Wing
• 3 x high-quality optical encoder wheels
• Supports one additional touchscreen
• Avokey security built-in
• Integrated UPS

Software

• Software platform: Avolites Titan
• DMX channels per device: 8192 max.
• DMX channels per system: 32,768
• 3D Visualisation: capture engine built in
• Max. fixtures: unlimited
• Keyframe effect engine: custom effects with any number of keyframes
• Pixel mapping: animation-based, video via Synergy
• External control: Web API, MIDI, DMX, sACN
• Titan Net: multi-user with any Titan console
• Output formats: Art-Net, sACN, or DMX-512
• OS: Microsoft Windows 10 Enterprise

Connectivity

• DMX-512: 4 x Neutrik 5-pin XLR, optically isolated
• Network: 2 x 1 Gb Ethernet connections
• Mains power: IEC
• Data / peripherals: 4 x USB 2.0 plus 1 x USB 2.0 front-mounted
• External display: Display Port and DVI (one active output only)
• MIDI: IN & OUT 5-pin DIN
• SMPTE: 3-pin XLR
• Switch trigger: 1/4″ jack
