TOP PRO XR24 Professional Audio Mixer Console 24 Channel

TOP PRO XR24 Professional Audio Mixer Console 24 Channel with DSP Effects & Bluetooth

The XR24 Professional Audio Mixer Console is a versatile and powerful solution designed for live performances, studios, broadcasting, and event setups. With 16 microphone inputs, 8 stereo inputs, advanced DSP processors, and digital connectivity, it combines professional-grade performance with user-friendly features.

Built with 48V phantom power, dual DSP digital effectors, Bluetooth input, USB recording, and MP3 playback, this XR24 Professional Audio Mixer Console ensures seamless integration for modern sound applications. Whether you’re a musician, DJ, sound engineer, or event organizer, this mixer provides the flexibility and reliability needed for both small and large-scale productions.

This XR24 Professional Audio Mixer Console delivers powerful sound processing, flexible routing, and modern digital convenience—making it the perfect choice for DJs, musicians, studios, event companies, and professional sound engineers.

Key Features

• Comprehensive Inputs & Outputs

  • 16 microphone channels + 8 stereo channels (4 groups).

  • Channels 1–8 & 17–24 with 80Hz low-cut function.

  • Channels 13–16 with a lotus input interface for convenient wiring.

  • Balanced & unbalanced main outputs with dual independent 60mm faders.

  • True two-group output with independent fader control.

  • 4 auxiliary outputs, 4 AUX sends, 2 FX sends, plus stereo auxiliary return.

  • Stereo monitor output for headphones or external speakers.

• Professional Sound Control

  • 3-band EQ (High, Mid, Low) on each input channel.

  • Peak and monitor indicators for precise sound monitoring.

  • Dual 12-segment beam level meters for accurate level indication.

• Advanced Digital Features

  • 48V phantom power for condenser microphones.

  • Built-in 2 DSP digital effectors with 198 effects comparable to professional processors.

  • Effect modes with LCD for intuitive control.

  • MP3 playback with LCD song display.

  • Bluetooth audio input for wireless streaming.

  • USB recording function with direct U-disk support.

  • Computer USB interface for direct audio input/output.

• Build & Design

  • Rugged design with unique appearance and SMT surface-mount technology for reliability.

  • Built-in switching power supply for stable and safe operation.

  • Compact, professional design suitable for both studio and stage.
